Stellantis EVPT VCU3000 in Bench

Program EVPT VCU3000 control units installed on Stellantis Group electric city cars.

As of today, you can perform the full backup with Fléchir via pinout, without the need to operate in Boot.

This new solution dramatically reduces working time and eliminates the need to open the unit, thus avoiding risks and potential damages.

An update designed to make every intervention faster, safer, and more reliable, maintaining the full read of the content of the unit.

Key insights

• Stellantis EVPT VCU3000 TC234L
  • Working Mode: Banc
  • Memories: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Backup
  • Licenses: FLS0.1M/S – FLS0.10M/S – FLS0.5M/S
  • Reading Time: ~ 40 seconds
  • Writing Time: ~ 20 seconds

Some of the supported vehicles

• Citroen AMI (I) (2020MY) 5.4kW 48V [8HP]
• FIAT Topolino (I) (2024MY) 5.4KW [8HP]
• Opel Rocks-e (I) (2021MY) 5.4kW 48V [IBSG] (6 electric)
